InApp NATIV

In-App Messaging is custom views that you can send to a segment of users to show custom messages or give new offers or take to some specific pages. They can be created from your MoEngage account.


Installing Android Dependency

Requirements for displaying images and GIFs in InApp

Note

Starting InApp version 7.0.0, SDK requires Glide to show images and GIFs in the in-apps. You need to add the below dependency in android/app/build.gradle  file.

Groovy
dependencies {
 ...
 implementation("com.github.bumptech.glide:glide:4.9.0")
}

Display In-App

Call the showInApp() wherever InApp has to be shown in the app as shown below :

JavaScript
import ReactMoE from 'react-native-moengage'
ReactMoE.showInApp()

Display Nudges

Starting with react-native-moengage version 9.0.0, MoEngage InApp SDK supports displaying Non-Intrusive nudges.

To show a Nudge InApp Campaign call showNudge()

JavaScript
import { ReactMoE, MoEngageNudgePosition } from "react-native-moengage";

ReactMoE.showNudge() // Display Nudge on any available position
ReactMoE.showNudge(MoEngageNudgePosition._NUDGE_POSITION) // Display Nudge on the specific position

InApp/Nudge Redirection default behavior

On clicking an Inapp or Nudge, MoEngage SDKs will handle only rich landing navigation redirection.

For the screen name and deep link redirection, your app code should redirect the user to the right screen or deep link. To handle the screen name and deep link redirection, you must implement inapp click callback methods. MoEngage SDK will just pass the inapp payload to this call back code. Implementation steps are mentioned in the InApp callback section of the Integration.

Self-Handled InApps

Self-handled In Apps are messages that the SDK delivers, but displaying them has to be handled by the app.

Single Self-Handled InApps

To get self-handled In-App call the below method.

JavaScript
import ReactMoE from 'react-native-moengage'
ReactMoE.getSelfHandledInApp();

The payload for self-handled in-app is returned via a callback. Register a callback as shown below.

JavaScript
import ReactMoE from 'react-native-moengage'
/// selfHandledCampaignData is of type MoESelfHandledCampaignData ReactMoE.setEventListener("inAppCampaignSelfHandled", (selfHandledPayload) => { if (selfHandledCampaignData && Object.keys(selfHandledPayload).length != 0) { console.log("inAppCampaignSelfHandled", selfHandledCampaignData); } });

Multiple Self-Handled InApps

info

Information

  • This feature is supported from version 11.1.0 of the plugin.

Fetch Multiple Self Handled Campaigns using getSelfHandledInApps()

JavaScript
import ReactMoE from 'react-native-moengage'
/// selfHandledCampaignsData is of type MoESelfHandledCampaignsData, which contains
/// a list of MoESelfHandledCampaignData data objects
var selfHandledCampaignsData = await ReactMoE.getSelfHandledInApps();

Tracking Statistics for Multiple Self-Handled In-Apps

The getSelfHandledInApps() method returns MoESelfHandledCampaignsDatawhich contains a list of  MoESelfHandledCampaignData objects. The statistics for each MoESelfHandledCampaignData  object must be tracked individually below APIs.

Fetching Contextual Multiple Self-Handled InApps

To fetch contextual multiple self-handled inapps, set the inapp contexts using setCurrentContext() before calling getSelfHandledInApps(). This will return a list of contextual and non-contextual inapps(in the order of campaign priority set at the time of campaign creation).

Tracking Statistics

Since display, click, and dismiss for Self-Handled InApp are controlled by the application we need you to notify the SDK whenever the In-App is Shown, Clicked, or Dismissed. Below are the methods you need to call to notify the SDK. The campaign object which is an instance of the MoESelfHandledCampaignData object provided to the application in the callback for self-handled in-app should be passed in as a parameter to the below APIs.

JavaScript
import ReactMoE from 'react-native-moengage'
ReactMoE.selfHandledShown(selfHandledCampaignData);
ReactMoE.selfHandledClicked(selfHandledCampaignData);
ReactMoE.selfHandledDismissed(selfHandledCampaignData);

InApp Callbacks

warning

Warning

The callbacks must be registered before inapps are displayed either via show methods or triggered events. And make sure you are calling initialize() the method of the plugin after you set up these callbacks. Refer doc for more info.

We provide callbacks whenever an InApp campaign is shown, dismissed, or clicked you can register for the same as shown below.

JavaScript
import ReactMoE from 'react-native-moengage'

///inAppInfo is of type MoEInAppData ReactMoE.setEventListener("inAppCampaignShown", (inAppInfo) => console.log("inAppCampaignShown", inAppInfo) );
///inAppInfo is of type MoEClickData ReactMoE.setEventListener("inAppCampaignClicked", (inAppInfo) => console.log("inAppCampaignClicked", inAppInfo) );
///inAppInfo is of type MoEInAppData ReactMoE.setEventListener("inAppCampaignDismissed", (inAppInfo) => console.log("inAppCampaignDismissed", inAppInfo) );
///inAppInfo is of type MoEClickData
ReactMoE.setEventListener("inAppCampaignCustomAction", (inAppInfo) => console.log("inAppCampaignCustomAction", inAppInfo) );
Event Type Event Name
InApp Shown inAppCampaignShown
InApp Clicked inAppCampaignClicked
InApp Dismissed inAppCampaignDismissed
InApp Clicked with Custom Action inAppCampaignCustomAction

Contextual InApp

You can restrict the in-apps based on the user's context in the application apart from restricting InApp campaigns on a specific screen/activity. To set the user's context in the application use setCurrentContext() API as shown below.

Set Context

Call the below method to set the context, before calling showInApp().

JavaScript
import ReactMoE from 'react-native-moengage'
// replace array elements with actual values. ReactMoE.setCurrentContext(['c1', 'c2', 'ce'])

Reset Context

Once the user is moving out of the context use the resetCurrentContext() API to reset/clear the existing context.

JavaScript
import ReactMoE from 'react-native-moengage'
ReactMoE.resetCurrentContext();

Payload Structure

TypeScript
 class MoEInAppData {
   /// account information
   accountMeta: MoEAccountMeta;

   /// Platform on which callback is received
   platform: MoEPlatform;

   ///InApp data
   campaignData: MoECampaignData;
 }

 class MoECampaignData {
  /// Unique Campaign Identifier
  campaignId: string;

  /// Campaign Name
  campaignName: string;

  /// additional information associated with Campaign
  context: MoECampaignContext;
 }

 class MoESelfHandledCampaignData {
   ///InApp data
   campaignData:MoECampaignData;

   /// account information
   accountMeta: MoEAccountMeta;

   ///Platform on which callback is received
   platform: MoEPlatform;

   ///SelfHandled data
   campaign: MoESelfHandledCampaign
 }

 class MoESelfHandledCampaign {
    ///Campaign Content provided while creating campaign
    payload: string;

    ///auto dismiss interval in seconds
    dismissInterval: Number;
 }

 class MoEClickData {
    ///account information
    accountMeta: MoEAccountMeta;

    ///Platform on which callback is received
    platform: MoEPlatform;

    ///InApp Data
    campaignData: MoECampaignData;

    ///InApp Click action
    action: MoEAction;
}

class MoEInAppCustomAction extends MoEAction{
   /// Key-Value pairs configured with action
   keyValuePair: Map<String, Object>;

   ///Click action type
   actionType: MoEActionType;
}

class MoEInAppNavigation extends MoEAction {
  ///navigation action type screen/deeplink
  navigationType: MoENavigationType;

  // ScreenName OR deeplink URL based on navigation type
  navigationUrl: String;

  // Key-Value pairs configured with action
  keyValuePair?: Map<String, Object>;

  ///Click action type
  actionType :MoEActionType;


// Model for Multiple SelfHandled Data
class MoESelfHandledCampaignsData {
    ///account information
    accountMeta: MoEAccountMeta;

    ///List of SelfHandled data
    campaigns: Array<MoESelfHandledCampaignData>
}



Handling Orientation Change

info

Note

This is only for the Android platform

Starting SDK version 7.3.0, in-apps are supported in both portrait and landscape modes.
SDK has to be notified when the device orientation changes for SDK to handle in-app display.

Add the API call in the Android native part of your app

Notify the SDK when onConfigurationChanged() API callback is received in your App's Activity class.

Java
import android.content.res.Configuration;
import androidx.annotation.NonNull;
import com.facebook.react.ReactActivity;
import com.moengage.react.MoEReactHelper;

public class MainActivity extends ReactActivity {

      /**
       * Returns the name of the main component registered from JavaScript. This is used to schedule
       * rendering of the component.
       */
      @Override
      protected String getMainComponentName() {
        return "SampleApp";
      }
      @Override public void onConfigurationChanged(@NonNull Configuration newConfig) {
        super.onConfigurationChanged(newConfig);
        MoEReactHelper.getInstance().onConfigurationChanged();
      }
}

Display status bar

To display the status bar, use the following code snippet during Android SDK initialization:

Java
.configureInApps(new InAppConfig(false))
